- Caterpillar 1017400 101-7400: M10-1.5 x 110mm Hex Socket Head Bolt | HEX SOCKET HEAD CAP SCREW / BOLT
1017400 CATERPILLAR 101-7400: M10-1.5 x 110mm Hex Socket Head Bolt | HEX SOCKET HEAD CAP SCREW / BOLT
| Manufacturer / Suplier | CATERPILLAR |
| Manufacturer's No. | 1017400 |
| Name | 101-7400: M10-1.5 x 110mm Hex Socket Head Bolt | HEX SOCKET HEAD CAP SCREW / BOLT |
Bolt Type: SOCKET HEAD BOLT
Material: STEEL
Material Description: ISO 898-1 Class 12.9. Head Marking - 12.9 (1220 MPa Ultimate Tensile Strength)
Coating: Zinc Flake
Thread Size (dia x pitch) (mm): M10 X 1.5
Bolt Length (mm): 110
Drive Type: INTERNAL HEX
Drive (mm): 8
Grip Length (mm): 78
Head Height (mm): 10
Flange Type: Smooth Flange Face
Head Diameter (mm): 16
Thread Size (mm): M10x1.5
Hex Size (mm): 8
Material: STEEL
Material Description: ISO 898-1 Class 12.9. Head Marking - 12.9 (1220 MPa Ultimate Tensile Strength)
Coating: Zinc Flake
Thread Size (dia x pitch) (mm): M10 X 1.5
Bolt Length (mm): 110
Drive Type: INTERNAL HEX
Drive (mm): 8
Grip Length (mm): 78
Head Height (mm): 10
Flange Type: Smooth Flange Face
Head Diameter (mm): 16
Thread Size (mm): M10x1.5
Hex Size (mm): 8
