1004982 CATERPILLAR 100-4982: M16 Hexagonal Head Bolt | Cat® M16 Steel Hexagonal Head Bolt with Locking Patch

Bolt Length (mm): 45
Bolt Type: Hex Head
Coating: Zinc Flake
Grip Length (mm): 6
Thread: Coarse
Head Height (mm): 10.32
Thread Size (mm): M16
Hole Thread Pitch: 2.00
Thread Size (dia x pitch) (mm): M16 x 2.00
Drive (mm): 24
Total Bolt Length - 3 (mm): 45
Finish: Zinc Flake
Head Width - 5 (mm): 24
Head Height - 4 (mm): 10
Grip Length - 2 (mm): 6
Grade: 10.9
Material Description: ISO 898-1 Class 10.9
Locking Feature: Nylon Patch
Finish Notes: Caterpillar is changing from Zinc Plating to a Zinc Flake finish for many bolts. The new coating improves corrosion protection to 720 hours. Until stock of the current plating is depleted, you may receive either finish due to the exhaust process.
Overall Length (mm): 45
Color Notes: Bolts sizes M6 through M12 with the new Zinc Flake finish will be black. Bolts sizes M14 through M36 with the new Zinc Flake finish will be gray. Until stock of the current finish is depleted, you may receive either the current or new bolt color.
