0862369 CATERPILLAR 086-2369: M10-1.5 x 130mm Hex Socket Head Bolt | HEX SOCKET HEAD CAP SCREW / BOLT
| Manufacturer / Suplier | CATERPILLAR |
| Manufacturer's No. | 0862369 |
| Name | 086-2369: M10-1.5 x 130mm Hex Socket Head Bolt | HEX SOCKET HEAD CAP SCREW / BOLT |
Thread Size (dia x pitch) (mm): M10X1.5
Bolt Length (mm): 130
Drive Type: INTERNAL HEX
Head Height (mm): 10
Grip Length (mm): 98
Drive (mm): 8
Head Diameter (mm): 16
Material: STEEL
Bolt Type: SOCKET HEAD BOLT
Material Description: ISO 898-1 Class 12.9. Head Marking - 12.9 (1220 MPa Ultimate Tensile Strength)
Head Width - 5 (mm): 16
Thread Size (mm): M10
Grip Length - 2 (mm): 98
Grade: 12.9
Thread: Coarse Thread UNC
Hole Thread Pitch: 1.50
Overall Length (mm): 130
Total Bolt Length - 3 (mm): 130
Bolt Length (mm): 130
Drive Type: INTERNAL HEX
Head Height (mm): 10
Grip Length (mm): 98
Drive (mm): 8
Head Diameter (mm): 16
Material: STEEL
Bolt Type: SOCKET HEAD BOLT
Material Description: ISO 898-1 Class 12.9. Head Marking - 12.9 (1220 MPa Ultimate Tensile Strength)
Head Width - 5 (mm): 16
Thread Size (mm): M10
Grip Length - 2 (mm): 98
Grade: 12.9
Thread: Coarse Thread UNC
Hole Thread Pitch: 1.50
Overall Length (mm): 130
Total Bolt Length - 3 (mm): 130
