0138307 CATERPILLAR 013-8307: 1/2''-20 x 1'' Hex Socket Head Bolt | HEX SOCKET HEAD CAP SCREW / BOLT
| Manufacturer / Suplier | CATERPILLAR |
| Manufacturer's No. | 0138307 |
| Name | 013-8307: 1/2''-20 x 1'' Hex Socket Head Bolt | HEX SOCKET HEAD CAP SCREW / BOLT |
Drive Type: INTERNAL HEX
Material: STEEL
Bolt Type: SOCKET HEAD BOLT
Material Description: ASTM A574. Head Marking - A574 (180 ksi Ultimate Tensile Strength)
Head Height (mm): 12.7
Thread Size (mm): .500
Head Diameter (mm): 19.05
Grade: 9
Thread: Fine Thread UNF
Hole Thread Pitch: 20
Drive (mm): 9.525
Overall Length (mm): 25.4
Grip Length (mm): 2.54
Material: STEEL
Bolt Type: SOCKET HEAD BOLT
Material Description: ASTM A574. Head Marking - A574 (180 ksi Ultimate Tensile Strength)
Head Height (mm): 12.7
Thread Size (mm): .500
Head Diameter (mm): 19.05
Grade: 9
Thread: Fine Thread UNF
Hole Thread Pitch: 20
Drive (mm): 9.525
Overall Length (mm): 25.4
Grip Length (mm): 2.54
