- Caterpillar 0069566 006-9566: 1/2''-20 x 1 1/8'' Hex Head Bolt | Hex Head Bolt
0069566 CATERPILLAR 006-9566: 1/2''-20 x 1 1/8'' Hex Head Bolt | Hex Head Bolt
| Manufacturer / Suplier | CATERPILLAR |
| Manufacturer's No. | 0069566 |
| Name | 006-9566: 1/2''-20 x 1 1/8'' Hex Head Bolt | Hex Head Bolt |
Bolt Length (mm): 28.57
Bolt Type: Hex Head
Grip Length (mm): 11.91
Thread: Fine
Material: Steel
Material Description: SAE J429 Grade 8. Head Marking - 6 radial lines (150 ksi Ultimate Tensile Strength)
Head Height (mm): 7.9375
Coating: 0
Thread Size (mm): .500
Grade: 8
Locking Feature: 0
Hole Thread Pitch: 20
Drive (mm): 20.6375
Overall Length (mm): 28.575
Bolt Type: Hex Head
Grip Length (mm): 11.91
Thread: Fine
Material: Steel
Material Description: SAE J429 Grade 8. Head Marking - 6 radial lines (150 ksi Ultimate Tensile Strength)
Head Height (mm): 7.9375
Coating: 0
Thread Size (mm): .500
Grade: 8
Locking Feature: 0
Hole Thread Pitch: 20
Drive (mm): 20.6375
Overall Length (mm): 28.575
